Description

Electrical System

• DC-actuator system (TUV & UL approved & EC60601-1)
• 24V out-put
• Voltage: 220-240V; 50Hz-60Hz
• Built in back-up battery

Accessories Included

• Medi-flex mattress with PU foam (23 Density) x 1 unit
  • – Mattress Approx Dim (mm): 1680 (L) x 790 (W) x 75 (H)
  • – Mattress cover with fire retardant, anti-bacterial, anti-static and waterproof

Technical Specifications

• Load Capacity: 180 kg
• Backrest: 75° / Legrest: 45°
• Overall Approx. Dim (mm): 1760 (L) x 890 (W)
• Hi-Lo: Approx. 540mm to 905mm (floor to mattress platform)
